Ref. 121A / PN 10-16 RESILIENT SEAT GATE VALVE NON-RISING STEM F4/F5

GENERAL CHARACTERISTICS

DAVINCI high-performance resilient seat gate valves are designed for demanding environments and 100% suitable for underground installations. Available from DN40 to DN1200, its full-bore design ensures minimum head loss, low torque, and 100% bidirectional tightness. It can also be repacked under pressure, reducing downtime and maintenance costs.

Manufactured according to leading international standards (DIN, EN, ISO, GB/T) and tested under strict EN/GB/T pressure protocols, this valve delivers proven reliability. It complies with EU Directive 2014/68/EU within the required categories and meets key potable water approvals, including WRAS, ACS, PZH, AWWA, and DM 174.

Protected with WRAS-approved epoxy coating (250 microns, RAL 5017), it offers long-lasting corrosion resistance making it a trusted solution for water networks, infrastructure, and industrial applications.

All kind of variations and adaptations can be done for your specific project, just ask for it. If you precise additional information a specific DAVINCI microsite project for our gate valves can be seen here: www.resilientseatgatevalves.com

Ref. 121A / PN 10-16 RESILIENT SEAT GATE VALVE NON-RISING STEM F4/F5

SKU: Ref. 121A / PN 10-16

Approvals/Standards
Design: DIN 3352
Manufacture according to: EN 1074-2./GB/T12232-1989
Face to Face: EN 558-1 Series 14/15 (F4/F5)
Mounting between flanges: PN10/16 EN 1092-2, ISO 7005-2.
Pressure Tests acc. to EN 12266-1 Rate A. GB/T13927-1992
Pressure Tests: Body: 1,5 x PN. Seat: 1,1 x PN
EU directive 2014/68/EU:
Products excluded, article 1, § 2b up to ND300. Risk Category I MoD. A from DN350 to DN600
WRAS PZH AWWA DM 174 Potable Water Projects Certified.
